Stand for Bose Satellites Speaker - Version II

The compact speaker stand for Bose satellites are designed in one piece. The speaker cable is routed inside the stand so that it is not visible. It first comes out of the base at the back. Due to the size, the speaker stand is ideal for a desk.

It is the 2nd version (remixe) of the speaker stand (my own remix, see changes below).

You will need a M5x16 screw to fix the bose satellite to the speaker stand.

IMPORTANT: please check your speaker model before you print the stand. My bose speakers has a M5 thread on the upper back side.

I printed the first version out of PETG with a layer height of 0.3mm (see print file). As the Bose satellite speakers are heavy, I increased the wall thickness during printing.  The organic support can be easily removed.

Enjoy printing

I made a remixe of my own model.

Changes:

1. two different hights - one suitable for PRUSA MINI und the 2nd, longer hight for MK3 & 4
2. Due to the wight of the speaker the stand bends a bit. I therefore added a lead angle of 1° to the upper part of the stand. When assembled, everything should now look straight.
3. The top surface of the base originally had a curved surface. This looked too stepped for my taste due to the 0.3mm pressure layer. Therefore, this has now been removed.

The other features should largely correspond to the first version.
