Extruded Aluminum Endcap for 40mm Two Slot 45 degree Triangle from 3d scan.
Endcap for 40mm Triangular aluminum extrusion. The CAD provided for this part is dimensionally inaccurate.
0
6
0
43
updated
January 26, 2025
Description
PDFThis model is from a 3d scan of triangular aluminum extrusion Mcmaster-Carr listing:
| Silver Anodized Aluminum—Smooth Rail Texture | ||||||
|---|---|---|---|---|---|---|
| 40mm | 40mm | Hollow | 8mm | 12.2mm | 45° | 6575N28 |
The included CAD drawing for this extrusion is dimensionally inaccurate as I tried to print multiple endcaps from this file and all were incorrect. I scanned the actual rail and modeled this endcap directly from that. Depending on your printer you may have to scale accordingly but on my X1C in PETGHF this worked just fine.
