JK BMS wall mounting plate
This utilizes the 4 M3 screw holes on the back of the BMS for mounting it to a surface, like a wall.
2
17
0
140
updated January 4, 2025
Description
PDFDue to the short cables of the BMS cables, it had to hang from the battery terminal. I didn't like that so I made this. Given the screw holes on the back, it made sense to use them.
Installation is simple.
4 countersunk M3 screws in each corner after which it's ready to be mounted on the wall or any other surface.
