X-Actamundo Hobby Knife

CDugD created this great little hobby knife that I've enjoyed for years. The way it feels in my hand is just nice. Printing this does favor warping on the end of the long handle. A brim is very helpful to assure good adhesion. ABS has always been a struggle. I've done it successfully in PETG. Reducing the sharpness of the handle would almost certainly help, but I like the aesthetic so I'm not messing with it.

CDugD's Description

A precision hobby knife that uses a standard utility blades instead of overpriced X-Acto ones.

An added benefit is that the blade can be reversed when it becomes dull; therefore, doubling the life of it.

The only additional hardware needed is a single 10mm m3 screw, m3 washer, and m3 nut.

-
A Relative Design project.
http://www.relativedesign.us/blog

See all our projects Here:
http://www.thingiverse.com/tag:relative_design

CDugD's Instructions

• Place a clean utility blade into the handle, making sure it is fully seated.
• Put the cover over the blade by first aligning the bottom edge under the small overhang and then pressing the top down over the blade. Again, make sure all parts are full seated.
• Place the nut into the hexagonal hole in the cover.
• Complete the assembly by inserting the m3 screw with washer through the back face of the handle and into the nut. Tighten the screw snugly.
