Mounting Grid Disk for 0.1" Spaced PCBs

The Mounting Grid Disk for 0.1" Spaced PCBs is inspired by the Adafruit Swirly Aluminum Mounting Grid for 0.1" Spaced PCBs. It is designed for cylindrical projects that integrate electronics prototyping. The disk has an outer diameter of 79.407 mm, a mounting grid diameter of 58.596 mm, and a height of 3 mm.

The disk includes four guides, each measuring 3.2 mm in diameter. Additionally, the mounting grid features guides with a diameter of 2.539 mm.
