JBL Clip 3 zip-tie Mount

This is a zip tie assisted bike mount for the JBL Clip 3.
Currently works on bikes with a flat top tube, will probably upgrade later to fit common round top tubes.

Demo video - https://youtu.be/nCgbRD90aPQ

Works great as a general-purpose mount for the clip 3 as you can zip tie it to anything.

Inspired by this video from Reddit - https://www.reddit.com/r/functionalprint/comments/h8szg1/snapfit\_speaker\_mount\_with\_extra\_layer\_of/

Couldn't find the file anywhere, OP didn't share it in the comments, so I went and made my own.

Supports are recommended, at an angle of 33 degrees.

I use support blockers in Cura in order to make sure there are no supports on the zip tie and button holes, although it is usually not a problem removing these supports.

Managed to print it on a stock Ender-3 without supports at 0.3 layer height and speed of 100 mm/s, but for the best results, supports are recommended.

Currently, the zip tie holes are very thin at the bottom (around 1mm). It does hold on, but I will make them thicker for a more fail-proof design.

**The model exports 90 degrees sideways, I now rotate it in the slicer until I will find the reason...

*EDIT: F3D file now available, sorry it took so long

Print Settings

Printer Brand:

Creality

Printer:

Ender 3

No

Supports:

Yes

0.15-0.2

Infill:

100%
