Bathroom Ventilator Cover

Fits standard Broan NuTone exhaust fans
26
47
0
396
updated January 5, 2025

Description

PDF

Bathroom Exhaust Vent Cover that fits standard Broan NuTone bathroom powered exhaust fans.

The original cover does not flow enough air to clear the steam from a hot shower. It is also difficult to clean and requires removal from the ceiling. This is a very common fan, but no one makes an alternative cover.

Replaces 235mm x 227mm (9.25" x 9") cover dimensions.

Replacement Grille for multiple models from Broan BP90, 688 Fan, Model S97011723, 99110808

M2 x 8mm bolts are used with the standard Broan spring clips to retain the cover to the fan enclosure.

Printed upside down, no supports, with PLA, 0.1-0.2LH, adaptic cubic 40% infill, 2 walls

(PLA - First layer 225°, others 235°C)

Included a couple of blank copies for custom patterns.

Please leave a “Like”, Thank you for downloading.

The updated impeller for this exhaust vent can be found here:

Upgraded Impeller
