Non-return valve for a kitchen hood / Zpětná klapka k kuchyňské digestoři
Parametric non-return valve fitting over the exhaust pipe(OD=111mm, but is parametric - can be easily changed).
1
9
0
77
updated December 16, 2024
Description
PDFThe model was created in FreeCAD 1.0 and should be edited in the same(i.e. Assembly workbench used was not present in earlier version).
Important Files:
- data.FCStd: contains spreadsheet that is used to set parameters for all parts of the model. Most important of those is the inner and outer diameter of the exhaust pipe and of the valve body
- assembly.FCStd: Assembled valve for preview and checking
- *.stl: exported parts, ready to print
There are prepared holes for possible counterweight to be bolted on.
