Tube Mounted Clutch and Brake Fluid Reservoir

For 3 hoses Built for 50mm but a washer will make it fit 2" and of course smaller ones.
0
2
0
21
updated December 15, 2024

Description

PDF

I made tube mounted brake fluid reservoir for my Monster Truck and it have two main/master brake cylinders so i made one with 4 hoses in PA12- CF.  It fits the big hated half twist of attached lid on pet bottles the 40mm ones if you can't find it there is one available but it may need some work.
You will probably not have any use for that but maybe a
1 for a hydraulic clutch,
2 for one main cylinder and a
3 for one main cylinder and one for a hydraulic clutch.
Built for 50mm tubes because I need a strong mounting place a washer will make it fit 2" and it will of course fit smaller ones. And it has 3 compartments connected at the top.
It must be sealed inside and out with epoxy before use not to much on the treads.
