Sliders for Endless UFS 90mm frame [FruitBoot Brand]

You got a 3D printer, you got some endless frames, why not customize them?
3
6
0
95
updated July 8, 2025

Description

PDF

These are sliders made for, well, sliding (and grinding) without ruining the pretty external walls of your lowkey expensive new frames.

Moreover, you can make 'em look pretty too! I'm gonna upload the .step files too so you can modify the design, add your name, colors, flags, cellphone number, Instagram @, the name of your pet tarantula, whatever you want, whatever you need!



Now let's talk specs!

First of all, you got them in two versions: Regular and Slim

  • Regular is made to look as similar as possible to the standard slider sold by endless. It even fooled the original creator for a second, it was early in the morning tho (or late in the evening? idk, I'm bad with timezones). Anyway, it should be very protective of your frame, i recommend it to be used on the outside walls.

  • Slim is made to be slim (duh), lightweight and minimal while still protecting your frame bolts and the bottom part of the frame from the meanest slides and slide-outs (if you catch my drift. If you don't, the ground will. ouch!) I'd recommend to use it on the inside walls of your frames or, for those of you who don't plan on grinding much, also on the outside to grant some protection to those fancy bolts.

Now, I'd recommend to print these using something like a PLA-ST or a PLA+, maybe also PETG will do good since it tends to be pretty smooth.

Give it a thick top surface (I went with 1.2mm top thickness) and thick walls (I gave mine 6 perimeters).
Infill almost doesn't matter, so keep it at you preferred standard value.

OH! one last Fun fact, they can be Printed on an Ender3 diagonally!

So Print ‘em, paint 'em, post ’em and tag me @rvrthebot on IG!



---------------------------------------

Lil disclaimer here:

These sliders are only compatible with the Endless UFS 90mm frames, they won't be compatible with the 80mm version (for, like, very obvious reasons) and are in no way meant to be for sale. In fact if you want to buy some I'd recommend you buy the original ones, since they will most probably slide better (and also support the creator of these wonderful frames).

---------------------------------------



p.s. I colored mine by pouring nail polish in the slots and text i printed. Have fun!
