Panasonic GH4 Camera Cage

This is a cheese grate camera cage for the Panasonic GH4.

https://www.thingiverse.com/thing:1691475 was the inspiration for this cage, but this was measured and modeled from my camera from scratch.

This cage has a proper hotshoe catch to completely lock the camera in position.

You'll need to use a drill to ream the holes to proper tap spec for 1/4" and 3/8" taps. If you print with PETG or ABS, and drill then tap each hole, there's more than enough grip to use them without brass inserts.

I printed this with 85% infill and 3 perimeters with PETG to produce an essentially solid part.

Print Settings

Printer:

RigidbotBig

Rafts:

No

No

Resolution:

.2mm

85%

Post-Printing

Step 1 - Ream Holes

Using a #7 drill bit for the 1/4 holes, ream out all holes with this bit. For the 3/8" holes, use a 5/16" drill bit.

Then use a SAE tap to tap the 1/4" and 3/8" holes as needed around the cheese grates
