DIN Rail Aubess Relay Mount

DIN Rail relay mount for Aubess, Athom and same form-factor cheap relays from AliExpress
11
58
0
314
updated December 10, 2024

Description

PDF

DIN Rail relay mount for Aubess, Athom and same form-factor cheap relays from AliExpress.
Designed for use with a base from https://www.printables.com/model/710771-din-rail-bracket
For assembly you need two M3x8 countersunk head screws, in my case it is DIN 7991
I printed it from ABS with a 0.2mm layer, 4 perimeters. ABS was chosen based on the fact that my electrical panel will be installed outside in the sun, and in the south it is very sunny here and the model has a small shrinkage compensation for a tight fit. The base is printed from PLA as recommended for that model
