Sofle Choc Wireless Case | dual 2000 mAh battery | pandaKB

Credits to danijoo for the original design! Life saver <3

I remixed this for the pandaKB which has the slider switch in a different location, as well as the female battery port.

PCB kit: Aliexpress

Battery: Aliexpress

If you need any minor change, chuck a comment below and I'll do my best.

PandaKB compatible by moving the cutout for the slide switch from side to top--this will no longer work with this: https://github.com/db-ok/SofleChocWireless

Thickened the base to add a recess for the battery (will fit a 306080 2000mAh 3mm battery)

Removed the recesses for magnets

Added holes for m3 inserts to add tenting later

Added recesses for silicone feet (10mm)

Moved the post to support the microcontroller to be compatible with the pandaKB version
