Qidi Q1 Pro Fan Shroud Remix.
Description
PDFUpdate - I now recommend using the original V2 as @8jack_346518 has added my change and more to the original. I am planning to work on a full properly flow simulated duct with a parametric feature for different nozzle lengths in the future but as I am quite busy I am not sure how long it will take since I more than likely have to rebuild the model from the ground up.
Remix of a fan shroud for the Q1 Pro that swiveled, added a bump that conforms to the turbo fan preventing the swivel. If you do try to swivel it, with enough force it will over come the notch but it won't swivel by itself or with reasonable force. I would like to make some more changes but its not really worth the effort without the step file.
12/1/2024
Slight update to tolerance to make it a tighter fit.
Tags
Model origin
The author remixed this model.
Differences of the remix compared to the original
Remix of a fan shroud for the Q1 Pro that swiveled, added a bump that conforms to the turbo fan preventing the swivel. If you do try to swivel it, with enough force it will over come the notch but it won't swivel by itself or with reasonable force. I would like to make some more changes but its not really worth the effort without the step file.
