Wallmounted tray for acoustic panel

Installing these storage options for your acoustic panels does not require any tools. They are designed in such a way that they stay on the wall simply by the force they exert on the ribs (in my case the shelf holds at least half a kilogram of load, this can vary from wall to wall, but it should definitely be enough for smaller objects )

The installation and removal should be done carefully, I recommend first inserting the top side into the wall at a 45 degree angle, this minimizes the stress on the ribs of the panels.

The only thing that really matters is the dimensions of your panels, which would be:

width of the ribs = 25mm

spacing of the ribs = 15mm

depth of the ribs = min.14mm

I used for mine the standard settings and added variable layer heights for a smoother bottom:

-quality/speed= 0.45

-radius= 10

-0.2mm layer

-2walls

-15%infill

-auto supports activated

I hope you can do something with the model. have fun printing!
