Neweer NB-Z1 Battery Cover for Neweer Z1 Z2 Z760 Speedlite Flash

I recently purchased a NEWEER Z1-N flash along with some friends and noticed there were no battery caps included.

According to the product page this battery is used for Z1, Z2 and Z760, however I've only tested it on my Z1-N.

As a result for my first model, I designed this basic cap in OpenSCAD based on the battery charger.

It's a tight fit but loosens nicely after the first couple of uses.


Printing Instructions

1. Open the OpenSCAD file
2. Set your desired scale_factor
   1. 1.05 for TPU 95A
   2. 1.0825 for PLA/PETG (tight)
3. Export the STL to your slicer of choice

Slicer Settings:

• Walls: 2
• Infill: 10% lightning
• Filament: Flex/TPU (I used Sunlu TPU 95A)

I've uploaded the OpenSCAD file along with the PrusaSlicer 3MF and GCODE for Prusa MK4S.

This model is for personal use only. Please do not use it for commercial purposes.

I'd love to see your makes!
