Clockhands for NEMA17 Stepper Motors

Do not guess the direction of your stepper motor any longer while developing code - just use a clockhand-style pointer
4m
1× print file
0.10 mm
0.40 mm
1.00 g
2
12
1
83
updated November 17, 2024

Description

PDF

Do not guess the direction of your stepper motor any longer while developing code - just use a clockhand-style pointer.

These parts are press-fit for NEMA17 axis, just print it with an as-fine-as-possible setting (I used 0.1mm Layers in Prusament PETG) and snap it onto the stepper motor.

There is a skinny and a bold version of the pointer, see the files attached.
