Multiboard Universal Build Plate Holder

Build plate holder for Multiboard. Two-piece design holds up to five plates of any single width.
29
95
2
401
updated November 17, 2024

Description

PDF

I wanted a build plate holder that could handle multiple plates, and mount on multiboard without feeling like it would pull off if I pulled out a plate badly.

Features of this holder:

  • Five slots, 1.2mm deep. Will hold even my thickest build plate.
  • Two pieces, place them at whatever width you need. The slots are 40mm wide on each side, so plenty of support if your width is not “perfect” on a 25mm increment.
  • Two pieces are much easier to print, will fit easily on small printers like the Prusa Mini or Bambu Mini.
  • Each slot is staggered by 5mm vertically, making it easier to see and pull the plate you want.
  • Mounts using four Large multiboard bolts, two on each side of the holder. A 9mm bolt should be sufficient, but I use 13mm because I'm paranoid. The holder is rock-solid on the multiboard.

Note: You will need to print four Large Multiboard Bolts 9mm or 13mm, these are not included in the print files. They can be found at https://www.multiboard.io/parts-library/threads/
