Gridfinity Tray for General Debur Tool and Automatic Punch

A Gridfinity tray I designed to hold my deburring tool, and No. 77 automatic center punch, which were both manufactured by General Hardware.  There are already gridfinity holders out there for both of these types of tools, but I didn't see any for these specific ones.  Since they both live in the same toolbox drawer, it made sense to combine them into one holder and save a little space.

Like my other Gridfinity models, the base is altered to accept 6x3 magnets as a press fit, with the upper surface of the magnet holes modified to make the slicer bridge across correctly for a clean result.  Due to the size of this model, I have included sacrificial “mouse ears” in the CAD to give the ends more surface area to help prevent them warping off the bed.  These will need to be removed after printing.

The unit pictured was printed out of Overture matte green PLA on my Bear upgraded Mk3S+, using a 0.6mm nozzle, at 0.3mm layer height.

Adaptation of Gridfinity system to hold General deburring tool and automatic center punch.
