Parametric LED Profile Clip

Parametric LED Profile Clip

This is a parametric LED profile holder designed in OpenSCAD, offering some parameters for customization. It is technically a remix of marr89's led profile clip with screw hole.

This model was first published on Thingiverse.

The default settings are set for LED profiles with a width of 18mm and a height of 7mm, usually holding a 10mm LED strip. The attached STL-file (LED Profile Clip.stl) has been rendered using this settings.

Parameter Overview

General Parameters

• Inner Width: The inner width of the clip in [mm]. This is the outer width of the LED profile plus a small margin (i.e. +0.1mm) to make it snap in more easy.
• Inner Height:T he inner height of the clip in [mm]. This is the outer height of the LED profile plus a small margin (i.e. +0.1mm) to make it snap in more easy.
• Length: This is the length of the clip itself in [mm].
•  Shell Thickness: Thickness of the arms and gripping ledge in [mm].
• Shell Backing Thickness: Thickness of the back of the clip in [mm].
  I found that,having less then 2mm can cause issues while printing.

Gripping Ledge Settings

• Gripping Ledge Size: Size of the gripping ledge in [mm].
• Gripping Ledge Snap: Enable snap-on for the gripping ledge.

Screw Settings

• Screw Diameter: Diameter of the hole for the screw in [mm].
• Screw Head Diameter: Diameter of the screw head in [mm].
• Screw Head Height: Height of the screw head in [mm]

## History

• 2024-11-11 Initial Upload to Printables.
• 2019-12-04 Initial upload to Thingiverse.

This model is more detailed and easier to customize. Most of the OpenSCAD code has been rewritten.
