a model of a knife using a popular type of razor
4
42
0
361
updated November 6, 2024

Description

PDF

since I couldn't find a suitable pocket knife anywhere that would use these blades, I had to make my own, it's quick to print and easy to assemble.
ATTENTION! Even though your razor looks the same, it may have slightly different hole spacing, so it is possible that you may have problems with the fit.



Even though this is the 6th version, it is not the final version, there are still a few things to improve



assembly instructions:

1.take the blade_holder and glue a pin to it from the bottom (this is the only moment requiring glue)

2. add blade

3. press blade_cover

4. put everything on main part

5. and finally slide on the cover
