BEST Robotics Low Profile Gizmo Case

This streamlined  Gizmo Case not only saves space but also provides some QOL features my team was wanting.

Features:

• The ports are sized and contoured to provide a more snug fit that will help keep the connectors from coming unplugged during use.
• The provided port label adds additional support for connectors while also giving you some clear labels for each port. We align this label plate with the connector ports and super glue these on for a permanent fit. This also allows adds additional support for the connectors. There is also a version included with the port labels recessed on the case top so you don't need to glue on the additional plate.
• The Pico covers no longer require a separate printed button (my team kept losing them every time they had to install another pico). In this model, the button is flex press and there is a bump on the other side that activates the RP Pico reset button.

The top screws to the base. I printed this on my Bambu X1 with detail settings and it came out great. All parts are designed to be able to be printed without supports.

UPDATE:

I have added updated Pi covers that have some ventilation holes for added air flow.

UPDATE #2:

Our competition requires a switch to be used between the battery and the board. This version is elongated with a 12mm x 19mm hole to allow for a rocker switch like this one to be used.

This is a remixed version of a streamlined Gizmo Case that saves a little space and provides some QOL features.
