Floor standing speakers

this is the model for a 3d printed floor standing speaker setup. incorporating a small transmission line to enhance bass
7
24
0
206
updated October 5, 2024

Description

PDF

this is a model for a floor standing speakers. uses a t-line for more performance. uses TWO 8 inch sub woofers in series (isobaric) a 4 inch mid driver and an 1.5 inch tweeter. I personnally repupossed a pair of broken Marrantz speakers, but feel free to use new components if you have the cash.

print settings as follows
optimum would be petg. but PLA will also work just fine (PETG has slightly better sound characteristics)
4 layer walls (3 if on 0.6mm nozzles) 25% or greater gyroid infill . will need supports but should be easy to remove.

will take about 10 kgs of fillament :|
i am doing this on an E3 S1 pro but would recomend larger machines
have fun
