XT30 Connector Case
Case for the XT30 connector and wire.
14
63
0
334
updated October 1, 2024
Description
PDFXT30 Connector case
I have made 2 designs, one is for a round wire that is approximately 3.5mm and the other is for a 16AWG/1.5mm2 wire (the proper wire thickness for xt30 according to the connector datasheet).
Print settings used:
- Printer: Creality Ender 3 v3 KE
- Resolution: 0.2mm
- Ironing: Yes, topmost layers only
- Infill: 10%
- Sliced in OrcaSlicer
