AxioT Container B705

Summary

This is the 70.5mm diameter type B container in the AxioT system. This diameter fits inside a Pringles can for easy carry/storage! For other sizes and system components, jump to the collection.

Portable and space-efficient, its core distinction is a central thread-post (vs threaded rim).

Divided variants are included and are especially handy for very small parts—parts remain separate when the container is closed. The lid also doubles as a staging tray and can be attached beneath the base to help keep your work area clutter-free while open.

Unit Type

This is the B-type variant and has a unit height of 7mm/U. This release includes 2U, 3U, and 4U containers.

Dividers

For models with dividers, segmentation is ‘clocked’ in 30° segments as with ‘hours’. In divided containers, the first divider at ‘00’ is assumed, with others depicted by either a series of 2-digits for non-periodic divisions, or a 2-digit span, ‘x’, and repeat count. (A bit complicated, but it works.)

Examples:
  0305 = dividers at 0, 3, and 5
  04x2 = dividers at 0, 4, and 8
  02x3 = dividers at 0, 2, 4, 6

For custom divider configurations, the desired 01x11 STEP file can be split (i.e. Bambu Studio > Split) for further customization.

Models

Container models are organized into folders by unit U size and file format.

Each container needs two parts: Base and Lid. Lids fit a Base having the same stack height (U) and diameter. Dividers are integrated into the Base part. Models are provided in both STEP and STL formats.

Printing

Print outside-down. Outer brim recommended, no supports.
