ESP32 Video Doorbell with Display

Case for LILYGO TTGO T-Camera with optional mounting of a dual channel relay (enables independent triggering of the…
2
8
0
96
updated September 23, 2024

Description

PDF

Case for LILYGO TTGO T-Camera with optional mounting of a dual channel relay (enables independent triggering of the gong and the camera)

This case was inspired by ESPHome-VideoDoorbell by petrepa https://github.com/petrepa/ESPHome-VideoDoorbell

LILYGO® TTGO T-Camera ESP32 Fisheye Lense V1.6.2 https://de.aliexpress.com/item/32968683765.html

AZDelivery 2-Relais Module 5V https://www.amazon.de/gp/product/B07LB2RQYP

Gebildet 12mm Edelstahl Taster 5V https://www.amazon.de/gp/product/B09Q8F5JR3

HSEAMALL Gewindeeinsatz 3d Druck https://www.amazon.de/dp/B07CPRHP2X

Category: DIY
