Mikrotik RB750 Gr3 HEX RACK MOUNT

Hello, this is my simple Rack Mount for Mikrotik RB750 Gr3 HEX. I designed this mount to use 1U space ( little bit less to allow some play)

Mount is made very thick and sturdy to allow pluging and unpluging of cables without holding device by other hand.

Device is mounted using 2x M4 screws with countersunk head. These screws fit in to Mikrotik original cross slot on bottom of device. When you place device inside and push it to the left side, it should lock to those screws. Additionally device is locked in place by power plug. When plug is inserted, you are not able to remove device from the mount.

If you dont have rubber feet on your mikrotik, just insert some spacers under device to align front hole with power socket.

Reset button is covered by front part, if you need you can still push it with needle or paper clip, but it is no longer possible to restart device by pen.

Right side USB, Mode button, front MicroSD as well as status LEDs are accessible.

If you want, You can change design as you wish, I uploaded STEP files as well.

Print Settings

Printer Brand:

Creality

Printer:

CR-10S

No

Supports:

Yes

.2

Infill:

20

Notes:

3 perimeters
5 layers top/bottom
