Corner Jig for Wood

This is a push-on jig to support corners of a wood box or frame while it is glued or nailed. It is sized for typical plywood. Two sizes are included 1/2" and 3/4". The actual gaps on these are 0.500" and 0.727", but any size can be made by scaling X&Y in your slicer. Also, if you are working on a shallow box, the height of the jigs can be reduced by rescaling the Z axis in the slicer. Even using PLA, these are quite strong.

Update 10-27-2021: Added STEP and Fusion 360 (fd3) files for easy remix. Please post all remixes for everyone to share..

Print Settings

Printer Brand:

Creality

Printer:

Ender 3

No

Supports:

No

0.2

Infill:

30%
