LEV50 Top Section
The US spec Mitsubishi I-MiEV battery pack contains 88 battery cells called LEV50. This model is the top of the cell.
1
15
0
35
updated September 18, 2024
Description
PDFTop section for model of LEV50 battery cell. Dimensions are 99% accurate as of 9/15/24.
The complete model can be used to help you mock up battery pack modifications.
Add two M8-1.25 x 15mm hex cap screws to 8mm holes in model for positive and negative terminals.
Use adhesive of choice to attach top cap to body of cell.
