Batpack - Case for RAK 19007 Meshtastic Kit

Here is a case for a RAK 19007 Meshtastic device. Includes solar charging, a GPS set to an ideal angle, 18650 holder, dot matrix for node ID, rails and holes for modular mounting options, and a side-located antenna to protect it and keep it more compact.

Print with supports everywhere. You may have to block off supports from small holes like the power switch screw holes, dot matrix holes, etc. Files not necessarily in ideal print orientation.

Happy to share the fusion file if you need it.

Printed Parts

• 1x base
• 1x user button
• 1x reset button (may require filing to get it to slide well in the case, as it has tricky little angles)
• 1x lid
• 1x screen cover (must be in TPU or other flexible materials)

Bill of Materials

• 1x RAK 19007 Meshtastic Starter Kit + GPS (GPS Optional)
• 4x screws from wisblock RAK kit
• 1x 18650 Battery
• 1x 2 position slide switch (19 x 6 x 13mm/ 0.75" x 0.24" x 0.51"(L*W*H)) https://www.aliexpress.us/item/3256806636284511.html
• 1x 10cm antenna connector (IPX UFL to SMA style of your choice)
• 1x Antenna
• 4x M3x10mm bolts (for lid)
• 2x M3x5mm bolts (for screen cover)
• 6x M3x5mm bolts *OPTIONAL (for mounting options)
• 4x M2x5mm bolts for screen
• 1x 6x6x4.3mm button, rip 2 legs off to fit the case after testing for continuity (6x6x5 may work)
• 1x .96" OLED screen
• 1x sheet of acrylic 2.3mm or thinner for screen cover. You cut to size (19x31mm)
• 1x 30x60mm solar panel (https://a.aliexpress.com/_msh2nDh the .25W one)
• 2x 3mm M3 threaded insert for holding screen cover (OPTIONAL 6x more for bottom for mounting options)
• 4x 4mm M3 threaded insert for holding lid to base
• 1x 4mm elastic paracord (OPTIONAL for bungie mount)
• misc wire, solder, heat shrink, hot glue for potting, E6000 glue for solar panel, etc.
