EmonTX Arduino Shield Enclosure

Designed to contain an Arduino Uno with an OpenEnergyMonitor EmonTX Shield mounted. The shield is connected to the primary power inlet for the house which allows me to monitor the overall power consumption for the property. The shield also supports a DS18B20 temperature probe which is also connected and monitored.

The shield is designed to use an RFM69CW RF Transmitter module however I rejigged this to use an ESP8266 (running EmonESP) to transmit the data to EMonCMS instead. I have detailed everything in my code on GitHub:

https://github.com/goldfishrock/EmonTX-Shield-Using-ESP8266-And-DS18B20-Temperature-Probe

The shield is available from OpenEnergyMonitor: https://shop.openenergymonitor.com/emontx-arduino-shield-smt/

Print Settings

Printer Brand:

Creality

Printer:

Ender 3 Pro

**Rafts:**

No

Supports:

Yes

**Resolution:**

0.20

Infill:

30%

**Filament:** ERYONE PLA White / Grey
