Lenovo Tiny PC 2x 1U Server Rack Mount

Printed with Ender 3 V2:

  Faceplate/Strut/Bowtie/Pins:

    Overture Starry Blue PETG

    No Supports

    Brim

    25% Gyroid Infill

    4 Walls - Outside to Inside - Alternate extra wall

    0.2 Layer Height

  Sled Parts:

    Overture Black PLA Pro

    No Supports

    No Bed Adhesion

    25% Gyroid Infill

    4 Walls - Outside to Inside - Alternate extra wall

    0.2 Layer Height

Minor cleanup changes to edges.

Resized faceplate to recess in rack and remove deep bevel.

moved foot recesses to location for Lenovo feet.

Created optional no-support versions of front and back sleds.
 - accomplished by removing recess for tiedown on bottom face.
 - will still need to print small overhangs for bowtie recesses.

Resized parts to fit Lenovo m700, m900, m720q. m93p.
 - may also fit other models, but I have none to test.
 - Opening is 180mm x 35.2mm. Lots of leeway for depth.

Oriented all models for print bed (235mm x 235mm).
