Model description

Concorde was the first commercial supersonic passenger airplane, built jointly by aircraft manufacturers in Great Britain and France.

From 1976 to 2003, it halved the time it took to cross the Atlantic Ocean by flying at twice the speed of sound. It was capable of ferrying passengers from New York to London or Paris in a just three and a half hours. The plane cruised higher than 50,000 feet, glancing out of the window would reveal the curvature of the Earth.

Passengers chose Concorde for its class, style and one of a kind experience. All over the world the futuristic design of Concorde turned heads of onlookers as it was truly an engineering marvel.

Assembly

The elevons and rudder pieces should be connected using pieces of 1.75 mm filament that are about 6 to 8 mm long.

Model dimensions

Length: 42,5 cm
Wingspan: 18 cm

Print settings

Layer height: 0,2 mm
Outer walls/perimeters: 2
Bottom layers: 3
Top layers: 5
Infill: 0% (except for the stand: 25%)
No supports
Minimum layer time: 5 sec
Perimeter generator: classic (not arachne)

Minimum required print volume for the Concorde is 126x126x192 mm.
