The Safety doorstop prevents the door from slamming abruptly by gently cushioning it.
This can, for example, prevent small children's fingers from being crushed when the door closes due to a gust of wind.
This also prevents glass breakage on doors that have thin glass panels.
In addition, this always leaves the door ajar so that your cat \ud83d\ude3a can always get in \ud83d\ude09.

If installation from below is possible, the door stop holds the door in position and functions like a normal door stop.

You can attach figures like this cute little mouse via a clip and add your own touch to the doorstop.

This is an improved design of the old Safety Door Stopper / Bumper V1 (2019 Design).

Features

Damping effect stops the door
No slamming doors
Compatibility: 7 different sizes available
Stability: very robust construction
Possible mounting options:
1. as a door bumper on the upper edge of the door, suitable for the area in the middle of the door up to the outer edge
2. as a door bumper on the side edge of the door
3. as a door stopper on the lower edge of the door

In various sizes

Size	Suitable for
Doorwidth *	Floor gap	Door weight
XS-2	8.0-22.0 mm [0.31-0.86 inch]	26.5-31.5 mm [1.04-1.24 inch]	Normal
L-1	37.5-48.5 mm [1.48-1.91 inch]	13.5-16.5 mm [0.53-0.65 inch]	Normal
L-2	37.5-48.5 mm [1.48-1.91 inch]	26.5-31.5 mm [1.04-1.24 inch]	Normal
XL-1	41.5-52.5 mm [1.63-2.06 inch]	13.5-16.5 mm [0.53-0.65 inch]	Normal
XL-1B	41.5-52.5 mm [1.63-2.06 inch]	15.5-18.5 mm [0.61-0.73 inch]	Heavy
XL-2	41.5-52.5 mm [1.63-2.06 inch]	26.5-31.5 mm [1.04-1.24 inch]	Normal
XL-2B	41.5-52.5 mm [1.63-2.06 inch]	28.5-33.5 mm [1.12-1.32 inch]	Heavy

* Suitable for the specified door width, without additional anti-slip pads. For more information, see the \" Application tips\" section.

Size XS-2: is intended for thin glass doors with a thickness of 8mm or more. Although the surface of glass doors is very slippery, tests have shown that foam rubber is not needed as an anti-slip measure. If so, more details in the Application Tips section.

Adaptability to different door widths

To simulate the maximum recommended clamping size on a door, I attached the door stop Size L-2 to a 37.5 mm (1.476 inch) thick door and also placed a 11 mm (0.43 inch) thick stack of paper in between, as shown in the image below. The red and yellow paper stacks are each 5 mm (0.2 inch) thick and the yellow one is 1 mm (0.04 inch) thick.

Figure: To illustrate the adaptability, I am using the size L-2 door stopper here.

Adaptability to different floor gaps

Here is an example of mounting from below to hold the door in position. The adaptability clearly has its limits here. If the gap fits, then the application is possible, if not, then not. The model has not been designed primarily for mounting from below. It should rather be seen as an option.

For which gap width, from floor to door, which variant is suitable, see table column 'Suitable for floor gap'.

Figure: To illustrate the adaptability to the floor gap, I am using the size L-2 door stopper here.

Choose the size according to the fit to your door frame profile

There are many different types of door frame constructions. The surface on the frame that the doorstop hits should be as vertical as possible.

Let's take a look at a special curved door frame profile.
A size xx-1 (e.g. XL-1) might fit better here than size xx-2 (e.g. XL-2), because it is lower.
The size xx-2 would hit the curved, sloping surface further up and push the doorstop down a little. If repeated frequently, this could lead to damage to the surface of the door frame, but it doesn't necessarily have to.

Figure: To illustrate, on this curved door frame profile, size xx-1 fits better than the slightly higher size xx-2.

If you have a special case, please let me know.

Print recommendations

Material: PETG
Nozzle diameter: 0.4 mm
Layer height: 0.2 mm
Perimeter: 6 **
Infill: 100%
Support: no

** It is important that the slicer does not generate infill, but only perimeters - with an extrusion width of 0.45 mm, I had 6 perimeters and for xx-xB models 8. To be on the safe side, I recommend simply entering a much higher number as the perimeter number in the slicer, e.g. 10.

Figure: The generated perimeters should then look like this

Application tips

You can use self-adhesive foam rubber or another rubber band:

to prevent slipping on very smooth door surfaces
to additionally protect the surface of the door
if your door is thinner than the specified minimum width, for example 37.5 mm (1.476 inches) for size L-1 and L-2

For example, thin foam rubber - with a thickness of 2.5 mm (0.1 inch) - with a one-sided adhesive layer is suitable.

Figure: Foam rubber - with a thickness of 2.5 mm (0.1 inch) here attached to size L-2

To calculate the appropriate foam rubber thickness, a 2.5 mm (0.1 inch) thick foam rubber (as shown in the picture) is compressed to approximately 2 mm (0.08 inch).

Clip-Type-PinA(Pin-Dia6mm-L15mm)

Festures

You can attach the clip to the doorstop very easily and without tools.
The clip has a pin to which you can attach a figurine, for example.
The type A pin has a diameter of 6 mm and a length of 15 mm.

Type	Size	Description
Pin-A	4.8mm	Tight fit on the 4.5 mm thick door stopper.
Pin-A	5.3mm	Loose fit on the 4.5 mm thick door stopper.

Print recommendations

Material: PETG
Nozzle diameter: 0.4 mm
Layer height: 0.2 mm
Extrusion witdh - exterernal Perimeter: 0.45 mm or smaller
Perimeter: 4
Infill: 15%
Support: yes
Brim: yes (only on outside if possible)
Slice gap closing radius: <0.05 mm

To be able to attach a figure, only a simple round hole needs to be added, with a diameter of 6.2 mm to 6.3 mm (depending on printing precision) and a depth of 16 mm. You can also do this very easily in the slicer. In PrusaSlicer, add a cylinder as a negative volume to the model.

Here I have attached the figure of a little mouse.

Updates

30 Oct 2023	V2 (internal revision 4) Initial release
6 Nov 2023	original 3D Model \u2018Door_bumper_V4_(2023)\u2019 renamed to \u2018Door bumper 2023-V4 Size L-2 (Door width 37.5-48.5mm - Floor gap 26.5-31.5mm)\u2019 added 4 Sizes XS-2, L-1, XL-1, XL-2 added printing advice for correct setting of the number of perimeters
14 Nov 2023	add a Clip in 2 Sizes so that you can attach figures and add your own touch to the doorstop
06 Mar 2024	added 2 Sizes XL-1B, XL-2B for heavy fireproof doors ;-)
