Features

No additional hardware needed

A G2 pen and filament are all you need.

Install and forget

Install and flexibly switch between plotting and 3D printing without removal of the attachment.

Tool free design

Slide in a spring and click the adapted cartridge into place. Easily remove by hand when complete.

Printer Support

Printer	Tool	Plotter Model	Installation	Homing	Calibration
MK4	G2 Pen	NEXTG2PP V8	\u2705@HeyHooper_607346	\u2705\u2754	\u2705\u2754
MK4S	G2 Pen	NEXTG2PP V8	\u2705Author	\u2705Author	\u2705Author
XL	G2 Pen	NEXTG2PP V8	\u274c\u2754	\u274c\u2754	\u274c\u2754
CORE One *	G2 Pen	NEXTG2PP V8	\u26a0\u2754*	\u274c\u2754	\u274c\u2754
MK4	FP Sharpie	NEXTFPSPP V5	\u2705\u2754	\u2705\u2754	\u2705\u2754
MK4S	FP Sharpie	NEXTFPSPP V5	\u2705Author	\u2705Author	\u2705Author
XL	FP Sharpie	NEXTFPSPP V5	\u274c\u2754	\u274c\u2754	\u274c\u2754
CORE One *	FP Sharpie	NEXTFPSPP V5	\u26a0\u2754*	\u274c\u2754	\u274c\u2754
MK4	FP Sharpie	NEXTFPSPP V10 Slim	\u2705\u2754	\u2705\u2754	\u2705\u2754
MK4S	FP Sharpie	NEXTFPSPP V10 Slim	\u2705\u2754	\u2705\u2754	\u2705\u2754
XL	FP Sharpie	NEXTFPSPP V10 Slim	\u274c\u2754	\u274c\u2754	\u274c\u2754
CORE One *	FP Sharpie	NEXTFPSPP V10 Slim	\u26a0\u2754*	\u274c\u2754	\u274c\u2754

* Installation is believed to be possible but unvalidated, however it is expected that homing and calibration sequences may not natively work with the adapter installed. Only attempt installation if you know what you are doing.

Download

G2 Pen

Latest G2 Pen Plotter (V8)

Latest G2 Spring to G2 Refill Adapter (V1)

Fine Point Sharpie

Latest Fine Point Sharpie Plotter (V10) Slim

Latest G2 Spring to Sharpie Adapter (V7)

Printing

For correct operation, these models requires dimensional accuracy within a tolerance of 0.1 mm. Filaments sensitive to moisture should be dried prior to printing.

Installation

MK4S

Disassemble the Nextruder into state shown on step 21.
Install pen plotter adapter onto the three M3x12 screws, while using it to keep the loveboard right in place.
Perform steps 22 to 42 taking extra caution as to not damage cables during step 22.

Example Usage

Open up the base project.3mf file present in the \u201cmodel files / examples\u201d folder.
Import the SVG you want to plot.
Set the SVG dimensions to X: 208, Y: 210, Z: 0.1 and center the SVG on the print bed.
Slice and load onto your printer.
Start the print and accept a \"wrong filament\" warning if no/wrong filament is loaded.
Printer will begin gcode, performing nozzle wipe (might remove in the future), bed leveling sequence, and then pause.
Place a sheet of US letter size paper on the bed aligning the top right corner with the top right of the bed.
- I keep the sheet of paper in place using 8mm wide binder clips at the top between the pins of the print bed and remove the top clips so they don't collide with the print head assembly. Painters tape on the margins can also be used to improve keeping positioning for plots that use a lot of ink.
Load the pen refill, adapter, and spring into the plotter.
Resume the plot and watch it begin the plot.
Enjoy the art :)

Be sure to share your make and art in the comments!

Merry plotmas!
