Flywheel designed to fit Xing 2207 motors. Might also be compatible with T19/Spirit.

Requires good layer & line adhesion to print properly.

Ensure your process can print steep overhangs. (Otherwise wheels will be very unbalanced.) I use 0.24 layer height, 0.48 line width, and 2 walls, 3 top/bottom layers. Concentric patterns w/o infill. Use ABS or other lightweight high temp filaments only.

Not extensively tested in the field yet, has only fired a few darts on a test bench setup. Unknown if the geometry conflicts with the cage.

Firmware contains my adaptations to the hardware I have.

06/17/2025: New updated version has been added, adjusted for weight reduction.

06/18/2025: Modifying this listing to be for all Phantasm edits I do.

","category":{"id":"51","path":[{"id":"48","name":"Hobby & Makers","nameEn":"Hobby & Makers","description":"Are you a maker? Everyone is, be a printer. Upgrade your home workshop and combine different materials and methods of crafting including 3D printing.","__typename":"CategoryType"},{"id":"51","name":"Mechanical Parts","nameEn":"Mechanical Parts","description":"Craft multi-purpose components with integrated assembly designs like nuts and screws, mechanically articulated arm, pulley systems, engine, and vice parts.","__typename":"CategoryType"}],"__typename":"CategoryType"},"modified":"2025-06-18T05:00:19.832240+00:00","firstPublish":"2025-06-01T03:24:28.323089+00:00","datePublished":"2025-06-18T05:00:19.812648+00:00","dateCreatedThingiverse":null,"nsfw":false,"aiGenerated":false,"politicalContent":false,"summary":"Experimental parts for the Phantasm dart blaster by gifd.","likesCount":2,"makesCount":1,"liked":null,"printDuration":null,"numPieces":0,"weight":null,"nozzleDiameters":null,"usedMaterial":null,"layerHeights":null,"mmu":false,"materials":[],"dateFeatured":null,"downloadCount":7,"displayCount":80,"filesCount":3,"privateCollectionsCount":2,"publicCollectionsCount":2,"pdfFilePath":"media/prints/1314390/pdfs/1314390-experimental-phantasm-parts-3fec4a0a-f2ce-45a1-8ff3-47dedfd9f615.pdf","commentCount":1,"userGcodeCount":0,"remixCount":0,"canBeRated":false,"addMakePermission":null,"printer":null,"image":{"id":"4519623","filePath":"media/prints/a11830fd-a672-4e6a-973a-151d3add818d/images/9915854_0ebeefe5-598a-4c63-812a-15f931cd40ae_2b8fe0f4-2882-4c86-96e3-74f50b50eab6/p-wheel.png","rotation":0,"imageHash":"UbcFDogIWGd5h3dwiYpoZ5h394Z/b/g=","imageWidth":832,"imageHeight":699,"__typename":"PrintImageType"},"images":[{"id":"4519623","filePath":"media/prints/a11830fd-a672-4e6a-973a-151d3add818d/images/9915854_0ebeefe5-598a-4c63-812a-15f931cd40ae_2b8fe0f4-2882-4c86-96e3-74f50b50eab6/p-wheel.png","rotation":0,"imageHash":"UbcFDogIWGd5h3dwiYpoZ5h394Z/b/g=","imageWidth":832,"imageHeight":699,"__typename":"PrintImageType"}],"imagesCount":1,"tags":[],"thingiverseLink":null,"filesType":null,"previewFile":null,"license":{"id":"4","disallowRemixing":false,"__typename":"LicenseType"},"remixParents":[{"id":"552908","modelId":"1302885","modelName":"Phantasm - A brushless foam dart blaster","modelAuthor":{"id":"1407012","handle":"gifd","verified":false,"publicUsername":"gifd","__typename":"UserType"},"model":{"id":"1302885","name":"Phantasm - A brushless foam dart blaster","slug":"phantasm-a-brushless-foam-dart-blaster","datePublished":"2025-10-01T00:40:05.345818+00:00","image":{"id":"4505784","filePath":"media/prints/e4821b24-304f-48cd-a22b-002d000ec3c1/images/9886933_2dd73e89-1851-4238-8d5f-e5e6f937187d_fdbefc8c-5e32-4520-b038-f0f4783c77de/img_3833.jpg","rotation":0,"imageHash":"lPgFBYYYeIiAeHiEiWeYeL/IhVz3","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},"club":false,"authorship":"author","license":{"id":"3","name":"Creative Commons \u2014 Attribution \u2014 Noncommercial","disallowRemixing":false,"__typename":"LicenseType"},"eduProject":null,"__typename":"PrintType"},"url":null,"urlAuthor":null,"urlImage":null,"urlTitle":null,"urlLicense":null,"urlLicenseText":null,"__typename":"PrintRemixType"}],"remixDescription":"

Flywheel:

Designed to fit Xing 2207 motors. Might also be compatible with T19/Spirit.

Uses original wheel-dart profile. Adds extra room around motor, requires good layer & line adhesion to print properly. Rest is custom geometry to fit the motor, reduce weight, and for aesthetics.

Firmware:

PhantasmPWMProMini.ino: EXTREMELY EXPERIMENTAL FIRMWARE, USE AT OWN RISK.

Changes from stock PWM/AM32 firmware:

Pinout changes for Arduino Pro Mini
Disabled low battery shutoff for testing purposes (eventually I want this to be a warning instead of a forced shutoff, but plan on moving to a new codebase)
Edited the default profiles to my spec - semi/auto/fast auto, speeds adjusted for 2750kv motors.
Moved the ESC arming to be just before loop() starts executing, as required by some SimonK ESC's.
