The bottle opener assists people with arthritis, limited finger dexterity or other disabilities to open standard water bottle caps (\u2300 30 mm or 1.18 in).

The device provides a large gripping surface and clamps onto the caps of standard water bottles with a small squeeze, allowing users to remove or screw on water bottle caps. It also has a narrowed feature that can be used to help open the pull tab of a can.

Print Settings

Infill: 50%

Resolution: 0.2mm

Supports: No

Rafts: No

Sizing Guide

Bottle Opener Version	Compatible Diameter of Caps (mm)	Example Containers
Bottle Opener 30	28-30	Pop bottles of all sizes (355 mL to 2 L) Bottled Water of all sizes (355 mL to 2 L) Milk Carton 2 L Juice Carton 2 L
Bottle Opener 35	33-36	Juice Jug (Some brands) 1.89 L Ketchup Bottle 1 L Juice Carton 900 mL
Bottle Opener 40	38-41	Sports Drink 591 mL Sports Drink 950 mL Juice Bottle 473 mL Iced Tea Bottle 473 mL Milk Bottle 473 mL Milk Jug 2 L Milk Jug 4 L Kefir Bottle 1 L
Bottle Opener 45	43-46	Juice Jug 1.46 L Juice Jug (Some Brands) 1.89 L Juice Jug 945 mL
Bottle Opener 50	48-51	3 L Juice Jug

Additional Documentation

https://github.com/makersmakingchange/Bottle-Opener

About Makers Making Change

Makers Making Change is an initiative of the Neil Squire Society, a Canadian non-profit that empowers people with disabilities through technology.

We leverage the capacity of community based Makers, Disability Professionals and Volunteers to develop and deliver affordable Open Source Assistive Technologies.

\ud83d\udd38 Volunteer to print a device

\ud83d\udd38 Tackle a design challenge

\ud83d\udd38 Submit an assistive device idea

\ud83d\udd38 Follow us on Instagram, Facebook, and Twitter
