Modular solutions for storing steel sheets for the PRUSA i3 (MK2.5 and MK3) and Bambu Labs (X1 and P1P)

Unlike my original steel sheet holder the GEN2 Steel Sheet Holder V2 does not require a backer mounted on the underside of the table directly behind it, this allows you to install it under any other GEN2 storage drawers and trays. It includes optional magnet slots on the redesigned back piece to pull the drawers into place.

NEW: If you have a Prusa Mini, Creality Ender 3, or any small to mid size printer with removable steel sheets, then the GEN2 Adjustable Steel Sheet Holder is what you want.

Originally designed for the \u201cOriginal Prusa i3 MK3 ENCLOSURE\u2026\", The Lack drawers have found their way on to many desks, workbenches, and other tables as well. Now with the Gen2's rail design you can quickly swap the storage units between work areas.

Features:
\u2022 Gen2 rails allowing quick and easier swap-ability and combinations of many Gen2 Storage System designs.
\u2022 Steel sheet holder is now one unit and can be installed directly to the GEN2 Rails or placed under any combination of full sized GEN2 drawers or trays.

HARDWARE
\u2022 Screwdriver
\u2022 Countersunk woodscrews: (Metric: 4x25mm to 4x16mm) or (SAE: #6 or #8 up to 1\" long)
\u2022 Drill bit that is smaller diameter than the wood screws
\u2022 Pen, Marker, or Scratch Awl
\u2022 Magnets (Optional): 10x5x2mm or 10x2mm
\u2022 M3 nuts
\u2022 M3 Screws M3x8 - M3x10

INSTRUCTIONS

*Note: Supported Printer Examples are for size reference only. These models are designed Specifically for the Prusa i3 MK2.5/MK3 and Bambu Labs X1/P1P.

This video covers the full assembly and installation of the GEN2 Steel Sheet Holder V2

\u2022 The Gen2 Steel Sheet Holder requires 3 rail units. The easiest way to add 3 units is by printing a Gen2 Rail Double Rail and a Gen2 Rail Single.

\u2022 Use templates to mark the hole locations on the surface you are mounting the desired sized rail to.

\u2022 Drill out marked locations using a drill bit smaller than the diameter of the wood screw you will be using.

\u2022 Prep the rail for installation by installing M3 nuts into the hexagonal holes. You can use a M3 screw to position and tighten the nut in place.

\u2022 Install the rail using wood screws, use at least 4 screws on the outer corners to mount the single rail and and 6 to mount the double rail. (extra screw holes are available if you plan to stack more than 2 rows of drawers or contents of heavier than normal weight.)

RECOMMENDED PRINT SETTINGS

Filament: PLA (PETG or ABS for heavier duty storage)
Nozzle Size: 0.4mm
Print Height: 0.2-0.35mm
Infill: 10-20%

","category":{"id":"40","path":[{"id":"1","name":"3D Printers","nameEn":"3D Printers","description":"Upgrading and improving your 3D printer couldn't be easier - no matter whether you're looking for functional or aesthetic modifications. Discover the best improvements.","__typename":"CategoryType"},{"id":"40","name":"Accessories","nameEn":"Accessories","description":"Add cool improvements to your 3D printer - drybox, filament buffer, or extruder visualizer. These smart ideas will make your printer even better!","__typename":"CategoryType"}],"__typename":"CategoryType"},"modified":"2024-11-02T01:28:10.907634+00:00","firstPublish":"2022-10-16T13:51:26.197897+00:00","datePublished":"2024-11-02T01:28:10.870894+00:00","dateCreatedThingiverse":null,"nsfw":false,"aiGenerated":false,"summary":"Modular steel sheet holder for installation under Lack Table Enclosures and GEN2 Lack Drawers. For PRUSA i3 & Bambu Labs","likesCount":1470,"makesCount":100,"liked":null,"printDuration":"15.68","numPieces":2,"weight":"185.00","nozzleDiameters":["0.40"],"usedMaterial":null,"layerHeights":["0.25"],"mmu":false,"materials":[{"id":"8","name":"PET","__typename":"MaterialTypeType"}],"dateFeatured":null,"downloadCount":3098,"displayCount":25352,"filesCount":14,"privateCollectionsCount":1255,"publicCollectionsCount":1073,"pdfFilePath":"media/prints/295913/pdfs/295913-gen2-steel-sheet-holder-v2-for-prusa-and-bambu-lab-a0caa7b7-1fb4-40a4-8fb3-3e0a02f887dc.pdf","commentCount":152,"userGcodeCount":0,"remixCount":6,"canBeRated":false,"addMakePermission":null,"printer":{"id":"1","name":"Prusa MK3/S/S+","__typename":"PrinterTypeType"},"image":{"id":"1381867","filePath":"media/prints/295913/images/2844642_024617de-a483-4c95-b0b4-24ceb72f99a0/gen2-steel-sheet-holder-v2-prusa-bambu-labs.png","rotation":0,"imageHash":"1okGHYY/SXhmqYermVeFmE+N89U4","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},"images":[{"id":"1381867","filePath":"media/prints/295913/images/2844642_024617de-a483-4c95-b0b4-24ceb72f99a0/gen2-steel-sheet-holder-v2-prusa-bambu-labs.png","rotation":0,"imageHash":"1okGHYY/SXhmqYermVeFmE+N89U4","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"1271980","filePath":"media/prints/295913/images/2599703_beac438f-cc6c-4057-8ccf-8d7f4a3c2ec3/pxl_20221015_231320295.jpg","rotation":0,"imageHash":"3LcFFYTwh0akZpefYlZohnV/HfKo","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"1272062","filePath":"media/prints/295913/images/2599863_c56117d4-e53e-4bc0-94b8-165156978fa3/dsc0036.jpg","rotation":0,"imageHash":"EkkGJYpUwIKKaWZWuKlIlwybtbBZ","imageWidth":4928,"imageHeight":3264,"__typename":"PrintImageType"},{"id":"1272063","filePath":"media/prints/295913/images/2599864_b109df57-bf9e-404b-9b11-34efa1075c48/dsc0033.jpg","rotation":0,"imageHash":"DnkKJY5Qp5WIeIeEeWiIhwVnZXBV","imageWidth":4928,"imageHeight":3264,"__typename":"PrintImageType"},{"id":"1272332","filePath":"media/prints/295913/images/2600430_cd309869-38ac-47cb-a33c-016b0d9f89ba/gen2-steel-sheet-holder-back.jpg","rotation":0,"imageHash":"FggKDYJ3iJCYileId5hnlPl3m5+o","imageWidth":3774,"imageHeight":2484,"__typename":"PrintImageType"}],"tags":[{"name":"prusa","id":"2","__typename":"TagType"},{"name":"table","id":"16","__typename":"TagType"},{"name":"organizer","id":"66","__typename":"TagType"},{"name":"wall","id":"76","__typename":"TagType"},{"name":"tool","id":"83","__typename":"TagType"},{"name":"ikea","id":"99","__typename":"TagType"},{"name":"mk3","id":"133","__typename":"TagType"},{"name":"holder","id":"165","__typename":"TagType"},{"name":"desk","id":"208","__typename":"TagType"},{"name":"mk2","id":"227","__typename":"TagType"},{"name":"container","id":"235","__typename":"TagType"},{"name":"mount","id":"469","__typename":"TagType"},{"name":"steel","id":"527","__typename":"TagType"},{"name":"i3","id":"627","__typename":"TagType"},{"name":"magnet","id":"676","__typename":"TagType"},{"name":"spring","id":"846","__typename":"TagType"},{"name":"enclosure","id":"850","__typename":"TagType"},{"name":"scale","id":"894","__typename":"TagType"},{"name":"stackable","id":"1089","__typename":"TagType"},{"name":"storage","id":"1916","__typename":"TagType"},{"name":"customizable","id":"1978","__typename":"TagType"},{"name":"lack","id":"2087","__typename":"TagType"},{"name":"bed","id":"2195","__typename":"TagType"},{"name":"tray","id":"2348","__typename":"TagType"},{"name":"magnetic","id":"2500","__typename":"TagType"},{"name":"bolt","id":"2768","__typename":"TagType"},{"name":"bin","id":"2890","__typename":"TagType"},{"name":"cabinet","id":"2922","__typename":"TagType"},{"name":"carbon","id":"2951","__typename":"TagType"},{"name":"slide","id":"3284","__typename":"TagType"},{"name":"flex","id":"3363","__typename":"TagType"},{"name":"rail","id":"3375","__typename":"TagType"},{"name":"bench","id":"3642","__typename":"TagType"},{"name":"labs","id":"3913","__typename":"TagType"},{"name":"caddy","id":"4001","__typename":"TagType"},{"name":"metal","id":"4398","__typename":"TagType"},{"name":"sheet","id":"4540","__typename":"TagType"},{"name":"drawer","id":"4909","__typename":"TagType"},{"name":"workbench","id":"4984","__typename":"TagType"},{"name":"pei","id":"5083","__typename":"TagType"},{"name":"customize","id":"5249","__typename":"TagType"},{"name":"under","id":"5650","__typename":"TagType"},{"name":"insert","id":"5662","__typename":"TagType"},{"name":"organize","id":"5719","__typename":"TagType"},{"name":"stack","id":"5960","__typename":"TagType"},{"name":"chamber","id":"7202","__typename":"TagType"},{"name":"textured","id":"7444","__typename":"TagType"},{"name":"swappable","id":"10694","__typename":"TagType"},{"name":"swap","id":"18098","__typename":"TagType"},{"name":"x1","id":"20071","__typename":"TagType"},{"name":"gen2","id":"20302","__typename":"TagType"},{"name":"removable","id":"30675","__typename":"TagType"},{"name":"bambu","id":"56805","__typename":"TagType"},{"name":"stud","id":"59962","__typename":"TagType"},{"name":"configure","id":"93801","__typename":"TagType"},{"name":"bambulabs","id":"108940","__typename":"TagType"},{"name":"p1p","id":"115465","__typename":"TagType"}],"thingiverseLink":null,"filesType":"GCODE","previewFile":{"id":"1340196","filePreviewPath":"media/prints/295913/stls/2599847_2cd663b8-c5b3-4cb3-9d25-93dfaadedb77/gen-2-test-print-parts_preview.png","__typename":"STLType"},"license":{"id":"1","disallowRemixing":false,"__typename":"LicenseType"},"remixParents":[{"id":"366811","modelId":"252219","modelName":"(LEGACY) Gen2 Steel Sheet Holder for Lack Enclosures","modelAuthor":{"id":"5751","handle":"Jerrari","verified":false,"publicUsername":"Jerrari","__typename":"UserType"},"model":{"id":"252219","name":"(LEGACY) Gen2 Steel Sheet Holder for Lack Enclosures","slug":"legacy-gen2-steel-sheet-holder-for-lack-enclosures","datePublished":"2024-03-16T18:40:39.955103+00:00","image":{"id":"1117848","filePath":"media/prints/252219/images/2267802_334176a1-1cd8-46aa-a159-7cf804fa0be1/steel-sheet-holder-thumbnail-v2.png","rotation":0,"imageHash":"m9cJLYgKOFNxeol0WHinZ5qflfp5","imageWidth":1648,"imageHeight":1114,"__typename":"PrintImageType"},"club":false,"authorship":"author","license":{"id":"1","name":"Creative Commons \u2014 Attribution","disallowRemixing":false,"__typename":"LicenseType"},"eduProject":null,"__typename":"PrintType"},"url":null,"urlAuthor":null,"urlImage":null,"urlTitle":null,"urlLicense":null,"urlLicenseText":null,"__typename":"PrintRemixType"}],"remixDescription":null,"__typename":"PrintType","user":{"id":"5751","handle":"Jerrari","verified":false,"dateVerified":null,"publicUsername":"Jerrari","avatarFilePath":"media/auth/avatars/7d/7d2e703b-a1a4-461e-a0ca-fd4089c9525c.png","badgesProfileLevel":{"profileLevel":36,"__typename":"BadgesProfileLevelType"},"__typename":"UserType","isFollowedByMe":false,"canBeFollowed":true,"designer":true}},"unavailableModel":null,"replies":[]}}}
