Buy here: https://www.etsy.com/uk/listing/1876691283/mjx-hyper-go-10208-shock-lift

This mod dramatically increases the droop and suspension range by moving the mounting point up 8-11mm. There is no drive shaft binding.

ride height:
front = 58 mm (11mm version)
rear = 55 mm (11mm version)

Instructions:

take note of the camber angle
remove lower shock mounting bolts
drill missing 3mm holes in stone shield
install shock lift part + stone shield with 2 M3x16 screw
reinstall shock with M3x16 screw and locknut
adjust camber angle

BOM:
M3 locknut x4
M3x16 bolt x8 (+ original shock screws)

Print Settings:
Print individually
TPU 95A
5-8 parameters
60% infill
