{"data":{"make":{"id":"1942002","created":"2024-07-24T00:30:51.872722+00:00","edited":"2024-07-24T00:34:13.954268+00:00","deleted":null,"isMake":true,"printer":{"id":"292","name":"Creality Ender 3 V2","__typename":"PrinterTypeType"},"parent":null,"author":{"id":"231391","handle":"piranhaphish","verified":false,"dateVerified":null,"publicUsername":"piranhaphish","avatarFilePath":"media/auth/avatars/ab/abf9782c-42af-4566-bce4-7f81f6c3b42a.png","badgesProfileLevel":{"profileLevel":14,"__typename":"BadgesProfileLevelType"},"__typename":"UserType"},"images":[{"id":"1762933","filePath":"media/comment_images/ef/a2815b-6a6d-4391-8de6-db24143b24a0/img_20240723_192311.jpg","rotation":0,"__typename":"CommentImageType"},{"id":"1762934","filePath":"media/comment_images/5e/d96e35-f096-41a9-ae45-a34dc44e387e/img_20240723_192323.jpg","rotation":0,"__typename":"CommentImageType"}],"mentions":[],"text":"Lots of fun. Well, not a *lot* of fun, but a *bit* of fun. But a *very* nice bit of fun.\n\nMy printer left a bit of stringing and seam bumps but, honestly, I think it worked out because, after sanding just a bit, it left an imperfect and slightly white finish which just makes it look that much more like a real carrot.\n\nThanks you and your wife for sharing.\n\nedit: FYI, printed as instructed but with 0.2mm layers which worked just fine.","rating":5,"likesCount":1,"liked":null,"membershipAgeMonths":null,"modelData":{"model":{"id":"949241","ratingAvg":"4.9444444444","ratingCount":18,"__typename":"PrintType"},"__typename":"ModelDataType"},"membershipTier":null,"__typename":"PrintCommentType","model":{"eligibleForNomination":false,"id":"949241","slug":"collapsible-carrot","name":"Collapsible Carrot","authorship":"author","club":false,"excludeCommercialUsage":false,"price":null,"eduProject":null,"ratingAvg":"4.9444444444","myRating":null,"ratingCount":18,"description":"

Nice collapsible carrot which can be magically pulled from your hand. Or from a combination safe lock box or from an egg shell.

Prints mostly in place, just the carrot tip have to be inserted into the collapsed carrot body and pushed firmly (e.g. by a screwdriver) until it clicks in. Best done while the main body is still on the printing plate. Then get it off the plate and pull the tip to get loose whatever may be stuck. UPDATE: Try the new v2 variant, it does not stick (I just rotated the smallest cone 90deg to print bridges in a better position.)

The leaf is best inserted like this: One side first (keeping the bigger side of the leaf in your fingers), press by thumb. Works nice for PETG, might be still a bit tricky with PLA. (I added more springy variant leaf-PLA.stl, you can try it out.)

Pull the carrot tip to fix it in the expanded form. Or pull in the middle and then put it on the table half-collapsed. Push to collapse it again.

Sorry, it is addictive. You did not think that you would play with collapsible carrots but once you print this, you will :) Fidget switch is nothing compared to the utmost carrot-like feeling and even the sound when you pull it by the tip and then collapse (yes, repeatedly).

You can also play checkers with it. Print carrots in two colors. Fix it in a bigger size to make a queen.

If you slice it yourself, check the top layers - flat top with a round hole is a bit tricky to print, I made very minimalist hexagonal progressive bridges to support it. These expect a 0.3 mm layer. Also two small parts use bridges (to keep the tip in place, and also the part next to the tip), these are much less sensitive.

It inspired my wife Denisa Vostra to draw the image of \u201cMrkvoun\u201d. Normally she writes Czech books but sometimes she draws funny pictures and sometimes she writes short funny poems with it.

She also recently invented a non-destructive baptism of new books using the collapsible carrots! In the collapsed state, the carrot resembles a glass and you can pour the carrot out and the book is not wet. You may notice multiple Czech celebrities on the picture - people who are even much better known to the public than this carrot is :)

Finally, thanks for all the downloads and likes. I'd always appreciate more makes. I already added the PLA leaf variant and improved assembly instructions based on the feedback from makes. Happy to hear more!

","category":{"id":"33","path":[{"id":"30","name":"Toys & Games","nameEn":"Toys & Games","description":"Idle hands are the devil's playgrou\u00adnd. Make yourself and your kids busy with some cool 3D printed games. Print items for both indoor and outdoor play.","__typename":"CategoryType"},{"id":"33","name":"Puzzles & Brain-teasers","nameEn":"Puzzles & Brain-teasers","description":"Shake your brains and figure it out! Print and solve all these clever puzzles, Rubik's cube, Cryptex, or Maze cube. Become a maze-hero and torture your friends.","__typename":"CategoryType"}],"__typename":"CategoryType"},"modified":"2025-04-05T13:09:30.527429+00:00","firstPublish":"2024-07-20T21:22:33.144991+00:00","datePublished":"2025-04-05T13:09:30.508433+00:00","dateCreatedThingiverse":null,"nsfw":false,"aiGenerated":false,"politicalContent":false,"summary":"Carrot can be magically pulled from the table and planted back, or fixed at any size. Addictive multisensory fidget.","likesCount":367,"makesCount":22,"liked":null,"printDuration":"0.59","numPieces":2,"weight":"9.00","nozzleDiameters":["0.40"],"usedMaterial":null,"layerHeights":["0.30"],"mmu":false,"materials":[{"id":"8","name":"PET","__typename":"MaterialTypeType"}],"dateFeatured":null,"downloadCount":1311,"displayCount":7115,"filesCount":9,"privateCollectionsCount":245,"publicCollectionsCount":153,"pdfFilePath":"media/prints/949241/pdfs/949241-collapsible-carrot-33b56076-f85e-4d44-a221-85262daa75bf.pdf","commentCount":69,"userGcodeCount":0,"remixCount":0,"canBeRated":false,"addMakePermission":null,"printer":{"id":"1","name":"Prusa MK3/S/S+","__typename":"PrinterTypeType"},"image":{"id":"3357923","filePath":"media/prints/949241/images/7245592_aedaab05-7bc2-4de4-a5f5-bccfb1d52872_5239d366-5eef-411f-ad08-5810e0bda289/img_2849.jpg","rotation":0,"imageHash":"1nkOHYyaeIePeHiKeJd4dzxzsAQX","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},"images":[{"id":"3357923","filePath":"media/prints/949241/images/7245592_aedaab05-7bc2-4de4-a5f5-bccfb1d52872_5239d366-5eef-411f-ad08-5810e0bda289/img_2849.jpg","rotation":0,"imageHash":"1nkOHYyaeIePeHiKeJd4dzxzsAQX","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"3357939","filePath":"media/prints/949241/images/7245625_cd8fc436-6e5b-4659-81d4-5f3c90437c38_aa659b29-91ea-42c8-a898-c884055e093b/pull_480.gif","rotation":0,"imageHash":"ligGNIqjvYtfhoizZaSbgLYIlw==","imageWidth":480,"imageHeight":270,"__typename":"PrintImageType"},{"id":"3357919","filePath":"media/prints/949241/images/7245595_4d33b1cf-4584-46d1-a92f-07ec0ab077e7_a774d0d5-ab12-4685-a707-c15337a23211/mrkf3.png","rotation":0,"imageHash":"mvgFRwqIl3Zwh4iHeHZ4mHeGeFA6clAF","imageWidth":1385,"imageHeight":1393,"__typename":"PrintImageType"},{"id":"3357920","filePath":"media/prints/949241/images/7245597_ba513283-f9f8-45e7-8560-99d155d79514_9d15fdca-0d38-4369-b978-5033fe08117a/mrkf.png","rotation":0,"imageHash":"XvcJF4A3uHeAeId1inZ3iHiIiEA4YOQP","imageWidth":1233,"imageHeight":1147,"__typename":"PrintImageType"},{"id":"3357921","filePath":"media/prints/949241/images/7245600_716a9ff7-f3e5-4d8f-a4e1-058ee4bddcab_69478951-bfdf-4b01-978c-6250e2617765/mrkf2.png","rotation":0,"imageHash":"nNcJFghniQaIh2iYdnmWiGd4DMolDIQ=","imageWidth":1268,"imageHeight":1388,"__typename":"PrintImageType"},{"id":"3357922","filePath":"media/prints/949241/images/7245598_b5d677b9-39b3-4e8f-9673-e90d01b609b3_cc67b084-eb19-4c1a-8f64-901ecb762888/img_2843.jpg","rotation":0,"imageHash":"VHoKHQZ5iH+Hl5end3p3mGqbsGQI","imageWidth":3024,"imageHeight":4032,"__typename":"PrintImageType"},{"id":"3359016","filePath":"media/prints/949241/images/7248046_475c7c46-7dc9-486d-980b-e83bd06e6025_9a3a7eab-b474-4ece-a1fc-eba1b6c1a598/mrkvoun-by-denisa-vostra.jpg","rotation":0,"imageHash":"MSkOLwb4h4iGeImadah4l3eIiaA3CHoD","imageWidth":1024,"imageHeight":1024,"__typename":"PrintImageType"},{"id":"3359105","filePath":"media/prints/949241/images/7248222_7d3bf920-22f7-4218-b3bf-cd13122889ee_870c6b71-fc00-49c3-868b-c523d3578fc0/img_2842.jpg","rotation":0,"imageHash":"mlkOJYh5mYhamHhviHiGd2mAlQU4","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"3359136","filePath":"media/prints/949241/images/7248301_6a0e1cb7-3202-46f4-997d-60ae4a57c1ca_11dbd95a-d1a4-42c4-8735-4944d5699fa4/img_2852.jpg","rotation":0,"imageHash":"1ygKDYJdpXaUZ3lvh5dqeS1wxtIH","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"3359106","filePath":"media/prints/949241/images/7248221_541b6290-9513-48f7-85dc-fafef8259222_87d03dac-8b36-4497-bf44-24e665c076d8/img_2857.jpg","rotation":0,"imageHash":"lEkGLYxkiXlQaIeWa7eWXTaGYHMI","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"3359137","filePath":"media/prints/949241/images/7248300_7c7e80eb-4fd4-4b21-b02d-076a2cb0a4c2_40df568e-b046-45d6-b5bb-0c7033bd46fe/img_2862.jpg","rotation":0,"imageHash":"1VkGHYaAjHhCd4erWYeXR1BWEZQG","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"3359179","filePath":"media/prints/949241/images/7248377_6295155a-3d84-44c8-a6f3-61ab2e75d9a7_5f547ca7-eb2e-49be-8418-57012c47d5b5/bottom-click-bridge.png","rotation":0,"imageHash":"2DgCJogFhKeIZYhgiUiHWKmHCYiSkCg=","imageWidth":2007,"imageHeight":1709,"__typename":"PrintImageType"},{"id":"3359178","filePath":"media/prints/949241/images/7248379_ef561ccc-ab44-468c-8d10-d9cb56c86513_eabca276-e15d-45fc-8389-b7938f72b84e/top-progressive-bridge.png","rotation":0,"imageHash":"2DgCHogncqWIZnhQmViGR5mXCoexkBk=","imageWidth":1894,"imageHeight":1658,"__typename":"PrintImageType"},{"id":"3359177","filePath":"media/prints/949241/images/7248378_eb4d6856-7af3-41f4-856c-1569cc9489b8_55eb3635-6dfc-49ab-bc1c-21a7e41cd82a/top-progressive-bridge2.png","rotation":0,"imageHash":"2DgCJogFg6eIZYlgiViGWJmHCYiSkCg=","imageWidth":2007,"imageHeight":1692,"__typename":"PrintImageType"},{"id":"3359180","filePath":"media/prints/949241/images/7248380_b705bb8a-0ed2-48ae-b574-49c4563dcbdb_d7074f6e-b330-47e8-80c7-9bfc81cfe127/top-progressive-bridge3.png","rotation":0,"imageHash":"FAgGBoD0mIZ3iIeLZXiImHiIsI148Zc=","imageWidth":2012,"imageHeight":1698,"__typename":"PrintImageType"},{"id":"3359381","filePath":"media/prints/949241/images/7248801_e2b40e30-822a-4be2-be1f-bc0f973963b7_f102c4b6-d751-40df-be7c-f707627f0250/img_2871.jpg","rotation":0,"imageHash":"EqoGNZJ1mnl0eHiQioiIikWVUGQJ","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"3359380","filePath":"media/prints/949241/images/7248802_fdeadee8-5d9f-4834-9c52-106fe9e52ba7_dc971b82-5cee-4a66-9f17-bd8602324013/img_2877.jpg","rotation":0,"imageHash":"E4oGLYxFd3lgWYdlaud2SxeAcRAJ","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"3359378","filePath":"media/prints/949241/images/7248805_e852c40e-2e2b-4608-8fa0-312c987b2eec_960baaee-9ff7-45f0-a83e-fb96c849b7f0/img_2880.jpg","rotation":0,"imageHash":"FIoGNY5QiHllaHene5aESkGFIGQJ","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"3359377","filePath":"media/prints/949241/images/7248804_c6bc0f62-c587-43a7-a96a-efa28791b587_100a68f0-9bd4-4c1c-a3ee-0101157a021d/img_2884.jpg","rotation":0,"imageHash":"E4oGLZBAh2hneGeXe4d0WjGGIHQI","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"3359379","filePath":"media/prints/949241/images/7248803_f4afa033-9f91-42de-9e2e-630dadd370eb_bde8c11c-d54b-4440-84ef-929934aa97ec/img_2890.jpg","rotation":0,"imageHash":"knkKLY55iHigd3eGiJiHiSWEQGII","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"3359396","filePath":"media/prints/949241/images/7248828_165b35df-c8a5-440d-a2da-ae68da50b827_de3cbade-411c-4d7e-8b01-9848cddc3b9e/img_2919.jpg","rotation":0,"imageHash":"E6oGPZZDZmZ1hYhAhxiHh1hngHUG","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"3359395","filePath":"media/prints/949241/images/7248827_99e55f67-3472-4cf8-a320-5dd9e16e1e48_f1d3bc69-ff06-47cd-98ed-1fa30eaf303f/img_2920.jpg","rotation":0,"imageHash":"k+oGJYxEM5GPl3lVmEl5eEZPUPUE","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"3359412","filePath":"media/prints/949241/images/7248927_1fe7257b-47c6-4037-a1cd-dbd1dfde9f4f_40e8d86c-9c86-401b-8bfe-445221a460a2/img_2921.jpg","rotation":0,"imageHash":"EvoJFZKZd4dqeXd/eKiWaw65yfn5","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"3359411","filePath":"media/prints/949241/images/7248926_0f3b461d-2ab1-40a8-b436-f3656626d199_96c68705-65ce-41fc-bf8b-a219943baa7a/img_2922.jpg","rotation":0,"imageHash":"E2oGJYr2lJssXneEWjdplzphoAQm","imageWidth":4032,"imageHeight":3024,"__typename":"PrintImageType"},{"id":"3380221","filePath":"media/prints/949241/images/7294501_151baacf-888a-441a-8909-4d8845412639_393e153c-f359-419e-bd0a-e5d93540efd7/fingercarrot.jpg","rotation":0,"imageHash":"1hgKDgYItLe1Z7eniJp2eFeXCI6FgFc=","imageWidth":3024,"imageHeight":3639,"__typename":"PrintImageType"},{"id":"3631275","filePath":"media/prints/949241/images/7845365_6edd9c3d-4526-4905-8ca6-b6dac7ae0403_f0086210-02c1-4c10-b35e-c62260d49706/krest.jpg","rotation":0,"imageHash":"1CgODYJ6d3d/lohpeYhniJ4ur2uA","imageWidth":2048,"imageHeight":1536,"__typename":"PrintImageType"},{"id":"3898574","filePath":"media/prints/949241/images/8458137_1971df79-da05-49fb-a696-4132f734edfa_05a1e8ef-e3b8-41dd-922d-ed773f2fa774/many.jpg","rotation":0,"imageHash":"0jkGFQqBHE+HRmU6iZZ3R1ewhwZa","imageWidth":3024,"imageHeight":4032,"__typename":"PrintImageType"}],"imagesCount":27,"tags":[{"name":"toy","id":"9","__typename":"TagType"},{"name":"fidget","id":"830","__typename":"TagType"},{"name":"printinplace","id":"1948","__typename":"TagType"},{"name":"nosupport","id":"6272","__typename":"TagType"},{"name":"collapsible","id":"10770","__typename":"TagType"},{"name":"carrot","id":"12850","__typename":"TagType"},{"name":"checkers","id":"20861","__typename":"TagType"}],"thingiverseLink":null,"filesType":"GCODE","previewFile":{"id":"3985792","filePreviewPath":"media/prints/949241/previews/64dffae56b5a3bac06e8edd98f44b77a651b4253.png","__typename":"STLType"},"license":{"id":"1","disallowRemixing":false,"__typename":"LicenseType"},"remixParents":[],"remixDescription":null,"__typename":"PrintType","user":{"id":"797838","handle":"vaclavh_797838","verified":false,"dateVerified":null,"publicUsername":"vaclavh","avatarFilePath":"media/auth/avatars/90/90543888-4bd8-4ec7-8a74-e88d076c490b.jpg","badgesProfileLevel":{"profileLevel":13,"__typename":"BadgesProfileLevelType"},"__typename":"UserType","isFollowedByMe":false,"canBeFollowed":true,"designer":false}},"unavailableModel":null,"replies":[{"id":"1942388","created":"2024-07-24T07:12:25.964369+00:00","edited":null,"deleted":null,"isMake":false,"printer":null,"parent":{"id":"1942002","__typename":"PrintCommentType"},"author":{"id":"797838","handle":"vaclavh_797838","verified":false,"dateVerified":null,"publicUsername":"vaclavh","avatarFilePath":"media/auth/avatars/90/90543888-4bd8-4ec7-8a74-e88d076c490b.jpg","badgesProfileLevel":{"profileLevel":13,"__typename":"BadgesProfileLevelType"},"__typename":"UserType"},"images":[],"mentions":[{"id":"231391","handle":"piranhaphish","__typename":"MentionListAssociationType"}],"text":"Thanks for the make ##user-231391## ! I had to try - and yes, you are right, sanding makes it more carrot-like :) Also happy to see it worked with different printer and different layer height. And my wife concluded that the world is sort of OK after all if people can have fun printing collapsible carrots.","rating":null,"likesCount":0,"liked":null,"membershipAgeMonths":null,"modelData":{"model":{"id":"949241","ratingAvg":"4.9444444444","ratingCount":18,"__typename":"PrintType"},"__typename":"ModelDataType"},"membershipTier":null,"__typename":"PrintCommentType"}]}}}
