Create your BaBo organizer! A system created to store them all!

Description:

This is the BaBo duo drawer modul 30. It is a spin off from the BaBo organizer system and was designed to be used under the AMS. The AMS adapter must be mounted at the top. If you want to place this module on your printer and dont want to use the riser, I recommend using the 20mm feet so that the drawer does not collide with the display.

It is only compatible with the [BaBo duo] modules and not with the [BaBo] modules. But you can use all babo inserts.

The usable dimensions of the drawer are 240x120x30.

The drawer has space for 8x4 inserts. They are two drawers

The inserts have a grid of 30x30mm, this means a 1x2 insert has the dimensions 30x60mm.

BaBo organizer is a stationary, very flexible system to store your tools, spare parts and even printing plates. The design is based on the iconic look of the Bambu Lab X1 printer. The entire system uses only 1 type of screw, M3x8 countersunk screws.

Join my club to expand this system and get access to exclusive modules.

BaBo collection

Update:

(31/10/23)

improved connection between modules
easier to push back the drawer
print profile optimizations

Bugfixes:

Printing:

Layer height: 0.2

Supports: No

Brim: No

Material: all

Assembly:

Follow the instructions in the picture.

printed parts
32 x M3x8 countersunk screws.

If you like this model, please throw me a like. Designing the models is time, filament and coffee consuming. If you want to support my work bye me a coffee (PayPal). Thanks!
