**Check Out The new improved version here**

This model is inspired by TomoDesign's stretch fidget but as you can see it is all my own design, so I have not done it as a remix. I have added seven sizes that are ready for printing but if you want more read down below on how to make your own unique parametric design.

HOW TO ALTER PARAMETERS:

When you open the file in openscad it should show these parameters right at the top:
width = 100;
ring_offset = -1.5;
vert_tol = 0.2;
gap_width = 3;
gap_height = 2+(vert_tol*2);
height = (gap_height-(vert_tol*2))*2;
layers = 2;
Simply change the numbers to you plant's size(mm) and then press F5 to preview your progress, once you are happy with the result export the file.

HOW TO EXPORT:

Once you have altered the parameters accordingly you can export the file as an stl for 3d printing, you do this by pressing F6 on your keyboard to render and then pressing file in the top right, then pressing export and then export as stl

Parameters:

width: The diameter of your design
ring_offset: Change this to make the ring slightly bigger or smaller to make it more 3d print friendly
vert_tol: the vertical gap between the parts
gap_width: the width of the horizontal gap(changing this can increase/decrease the squishyness of the model )
gap_height: The height of the gap, this is a big contribute to the overall height of the design (only change the first number)
height: DO NOT CHANGE
layers: The amount of stacks of the interlocking grid, increasing this will give the model more strength.(I highly recommend 2, but you can experiment with more or less)

If you like this please consider joining my club for exclusive models and a commercial licence and even CUSTOM DESIGNS FOR YOU!

","category":{"id":"47","path":[{"id":"30","name":"Toys & Games","nameEn":"Toys & Games","description":"Idle hands are the devil's playgrou\u00adnd. Make yourself and your kids busy with some cool 3D printed games. Print items for both indoor and outdoor play.","__typename":"CategoryType"},{"id":"47","name":"Other Toys & Games","nameEn":"Other Toys & Games","description":"Toys for kids of all ages, boys, and girls alike. Play with Flexi animals, fidget toys, dollhouse sets, or swords. Or find a toy for yourself.","__typename":"CategoryType"}],"__typename":"CategoryType"},"modified":"2025-02-03T17:03:01.072545+00:00","firstPublish":"2024-05-03T17:31:53.129338+00:00","datePublished":"2025-02-03T17:03:01.051122+00:00","dateCreatedThingiverse":null,"nsfw":false,"aiGenerated":false,"summary":"This is an extremely satisfying and fully parametric squishy fidget","likesCount":2166,"makesCount":150,"liked":null,"printDuration":null,"numPieces":0,"weight":null,"nozzleDiameters":null,"usedMaterial":null,"layerHeights":null,"mmu":false,"materials":[],"dateFeatured":null,"downloadCount":22515,"displayCount":58667,"filesCount":8,"privateCollectionsCount":1366,"publicCollectionsCount":822,"pdfFilePath":"media/prints/866943/pdfs/866943-fidget-squish-fidget-b6037a92-a30a-4d7e-b893-d9d54111c8a1.pdf","commentCount":182,"userGcodeCount":0,"remixCount":0,"canBeRated":false,"printer":null,"image":{"id":"3096880","filePath":"media/prints/866943/images/6655338_cc7eb3cc-efd8-41cb-95da-2c222d2e68c0_7c679e33-cbfb-4955-aec7-088e656c66f5/20240503_182612.jpg","rotation":0,"imageHash":"1OcFLQpklY+JeId4ZGV3h5BTCTql","imageWidth":3060,"imageHeight":4080,"__typename":"PrintImageType"},"images":[{"id":"3096880","filePath":"media/prints/866943/images/6655338_cc7eb3cc-efd8-41cb-95da-2c222d2e68c0_7c679e33-cbfb-4955-aec7-088e656c66f5/20240503_182612.jpg","rotation":0,"imageHash":"1OcFLQpklY+JeId4ZGV3h5BTCTql","imageWidth":3060,"imageHeight":4080,"__typename":"PrintImageType"},{"id":"3096878","filePath":"media/prints/866943/images/6655337_96290aa9-65e6-4196-8c6a-98c3aafa085f_67b1e024-fb4f-4ad9-875b-bb21fd1f960e/20240503_182725.jpg","rotation":0,"imageHash":"kygSFQaHZo94l4iHiHh4hw2P9PFZ","imageWidth":3060,"imageHeight":4080,"__typename":"PrintImageType"},{"id":"3096877","filePath":"media/prints/866943/images/6655336_920154d7-d2fe-49d7-afb6-6e52ce8dfe5e_129c4e02-d4bb-4998-b820-91e4b35bba82/20240503_182758.jpg","rotation":0,"imageHash":"XMcFLQxmdkKH2Eh2d2w1P7d3f3v2","imageWidth":3060,"imageHeight":4080,"__typename":"PrintImageType"},{"id":"3096879","filePath":"media/prints/866943/images/6655339_961d2a94-2652-44df-9f22-08810a2add7a_98e425c7-5b88-4c44-8eaf-076897a0787c/20240503_182639.jpg","rotation":0,"imageHash":"2SgKFQaMeUB3qJdll1iHlw5x8QAV","imageWidth":3060,"imageHeight":4080,"__typename":"PrintImageType"}],"tags":[{"name":"fidget","id":"830","__typename":"TagType"},{"name":"stretch","id":"43312","__typename":"TagType"}],"thingiverseLink":null,"filesType":null,"previewFile":{"id":"3658343","filePreviewPath":"media/prints/866943/previews/51eb0a5718e5cbcf982e459c3fa540eb98a40853.png","__typename":"STLType"},"license":{"id":"3","disallowRemixing":false,"__typename":"LicenseType"},"remixParents":[],"remixDescription":null,"__typename":"PrintType","user":{"id":"848697","handle":"KingTut","verified":false,"dateVerified":null,"publicUsername":"KingTut","avatarFilePath":"media/auth/avatars/94/94e4f871-bbd8-40f1-be9a-32e789187294.jpg","badgesProfileLevel":{"profileLevel":20,"__typename":"BadgesProfileLevelType"},"__typename":"UserType","isFollowedByMe":false,"canBeFollowed":true,"designer":true}},"unavailableModel":null,"replies":[]}}}
