Das ist ein optimierter Looping, dessen Einlauf an die Steigung der Schiene angepasst wurde.

Somit ist es m\u00f6glich mit einer Standardschiene und 4,5cm oder 5cm H\u00f6hensteinen, eine Kugel durch den Looping zu schicken.

Wenn die Kugel mit etwas Schwung ankommt, reichen 4,5cm an H\u00f6hensteinen aus, mit 5cm H\u00f6hensteinen ben\u00f6tigt die Kugel keine gro\u00dfe Anfangsgeschwindigkeit.

Wichtig ist, dass die Spur des Looping mit Schleifpapier gut geschliffen wird.

Es gibt eine \u201enormale\u201c Version, und eine zum drucken optimierte, die an der Oberseite offen ist.

Da bei 5cm H\u00f6hensteine die Standardschiene nicht mehr richtig passt, sollte hier die optimierte 3er Schiene gedruckt werden. (ist 1mm l\u00e4nger als die originale)

\u00dcber eine R\u00fcckmeldung, wie das Model zu drucken ging und wie die Kugeln bei euch laufen, w\u00fcrde ich mich freuen.

Video

some Expression

English

This is an optimized loop, whose entry has been adapted to the incline of the track.

It is therefore possible to send a ball through the loop with a standard rail and 4.5cm or 5cm height stones.

If the ball arrives with a bit of momentum, 4.5cm of height stones are sufficient, with 5cm height stones the ball does not need great initial speed.

It is important that the trace of the looping is sanded well with sandpaper.

There is a \"normal\" version, and one optimized for printing, which is open at the top.

Since the standard rail no longer fits properly with 5cm height stones, the optimized 3-rail should be printed here. (is 1mm longer than the original)

I would be happy to get feedback on how the model went to print and how the balls are running with you.
