This can be printed as two separate prints. You need to enable z-hop (0,6mm is enough). You can enable z-hop only for first several layers (in Super slicer at least). First you print hexagons and on top of that main body. If you z homing in the middle off the bed you need to move it in slicer a little to make space for your probe. Dont forget to disable mesh leveling for second print. Disable skirt or brim on first print. Remove purge line after first print is done. Its designed for 0,2mm layer height.

Just use IDEX printer. Or other multi material solution.

Both files are proper oriented for printing.

For alingment you need to move hexagons +1,2mm on Y in slicer and do some minor alingments.

Inspiration:

https://www.printables.com/en/model/225153-voron-stealthburner-face

22.10.22 New files with more clearance.

24.01.23 Added SB main body without gaps (chamfers)

12.03.2023 Added remix of Panzerkatten 3DO cam grille SB body

https://github.com/3DO-EU/nozzle-camera/tree/main/printers/Voron_Stealthburner
