Inspired by https://www.printables.com/model/122378-cable-organizer-cable-clip

I liked this design but:

I want to organise larger cables (e.g HDMI, mains leads)
I have cables of different lengths
I want the clip to stay with the cable when unwound (so I don't lose it)

I designed this from scratch in OpenScad, based on the design linked above.

This is a parameterised model. You can choose:

the cable diameter you have
how many loops of cable you are trying to hold
the height of the clip
the overall width
if you want a 'clip' to attach to the cable when unwound
a modified design if you are using flex filament

With this you can now get a customised clip for each cable, that fits it perfectly.

There is also a checkbox if you want to used TPU/TPE or any flexible filament. In this case the thickness is increased and the cable gap is reduced. Uncheck this if you are using PLA / PETG.

To use, open the .scad file in OpenScad. Ensure the customizer is showing (menu \u2192 Windows \u2192 Customizer), then enter the measurements for your cable.

There are limits when you increase the cable size/loops; if you get an error, increase the width, as there needs to be enough width to fit all loops.

This prints very easy on its side, no support needed.
