Cap/Cover for female Ethernet Ports to prevent dust from getting inside. Easy to print without any supports. You can use a brim if you have adhesion problems.

Both, PLA and PETG, are fine. But I would suggest to use PLA, because PETG has a tendency to bend down while printing if you have insufficient part cooling. I also suggest a 0.12 - 0.16mm layer height. In the picture you'll find a comparison about the different settings.

Also try to print multiple covers at once, to give each layer more time to cool. I personally print them in a batch of nine.

Update 19.01.2023 - Steeper version

I've added a version with a steeper connection between the handle and the cover. This might be better printable on printers with less good cooling or materials that may tend to bend down.

Update 21.01.2023 - Reinforced v2

I've added a new version of both models with a reinforced connection between the cover and the part going into the Ethernet port. This may prevent cracks at this point.

","category":{"id":"27","path":[{"id":"21","name":"Gadgets","nameEn":"Gadgets","description":"Everyone loves smart gadgets. Use 3D printing to make amazing items for audio, photo & video, computers, and phones. Top models are ready to download for free.","__typename":"CategoryType"},{"id":"27","name":"Computers","nameEn":"Computers","description":"Tons of laptop and PC gaming 3D printable accessories and components of all kinds will amaze you. Make great projects with Raspberry Pi and other tech gadgets.","__typename":"CategoryType"}],"__typename":"CategoryType"},"modified":"2023-01-22T11:40:17.310139+00:00","firstPublish":"2022-12-28T16:18:52+00:00","datePublished":"2023-01-22T11:40:17.279447+00:00","dateCreatedThingiverse":null,"nsfw":false,"aiGenerated":false,"politicalContent":false,"summary":"Dust-cover for female Ethernet Ports.","likesCount":3238,"makesCount":164,"liked":null,"printDuration":null,"numPieces":0,"weight":null,"nozzleDiameters":null,"usedMaterial":null,"layerHeights":null,"mmu":false,"materials":[],"dateFeatured":"2023-07-03T10:41:58.026526+00:00","downloadCount":8343,"displayCount":30279,"filesCount":4,"privateCollectionsCount":2942,"publicCollectionsCount":1613,"pdfFilePath":"media/prints/351646/pdfs/351646-ethernet-port-dust-capcover-no-supports-54cf0385-5cca-4226-97db-cb2377ea0f09.pdf","commentCount":205,"userGcodeCount":1,"remixCount":3,"canBeRated":false,"addMakePermission":null,"printer":null,"image":{"id":"1449555","filePath":"media/prints/351646/images/2985392_b4cca00b-1277-4c2c-8d77-07391d85d41a/pxl_20221228_161019373.jpg","rotation":0,"imageHash":"IQgWDgJ5d/d3eHiGh4d4iHd3jH+F93g=","imageWidth":2028,"imageHeight":2535,"__typename":"PrintImageType"},"images":[{"id":"1449555","filePath":"media/prints/351646/images/2985392_b4cca00b-1277-4c2c-8d77-07391d85d41a/pxl_20221228_161019373.jpg","rotation":0,"imageHash":"IQgWDgJ5d/d3eHiGh4d4iHd3jH+F93g=","imageWidth":2028,"imageHeight":2535,"__typename":"PrintImageType"},{"id":"1449550","filePath":"media/prints/351646/images/2985369_89461362-24a2-40a5-ab5a-0f66b527da56/pxl_20221228_160855889.jpg","rotation":0,"imageHash":"WhgKBgABiqd1iliJhpZmhYk4AVsEsVY=","imageWidth":2156,"imageHeight":2696,"__typename":"PrintImageType"},{"id":"1449552","filePath":"media/prints/351646/images/2985383_d7c98b8a-a437-42a1-a73f-b426182367ea/pxl_20221228_161005457.jpg","rotation":0,"imageHash":"JggGBoAMK0m7p5iGhqaHpoZpH5/A8Fw=","imageWidth":2164,"imageHeight":1732,"__typename":"PrintImageType"},{"id":"1490237","filePath":"media/prints/351646/images/3077971_02a94478-d4f6-424f-a959-1b30f425c59e/pxl_20230109_110420517-kopie.jpg","rotation":0,"imageHash":"NwgKDYB3aOi5iGd/d2mDh3lQhwmG","imageWidth":1751,"imageHeight":1251,"__typename":"PrintImageType"}],"imagesCount":4,"tags":[{"name":"cap","id":"730","__typename":"TagType"},{"name":"cover","id":"2164","__typename":"TagType"},{"name":"ethernet","id":"2515","__typename":"TagType"},{"name":"dust","id":"2947","__typename":"TagType"},{"name":"ethernetjack","id":"9564","__typename":"TagType"},{"name":"dustcover","id":"11652","__typename":"TagType"},{"name":"ethernetclip","id":"34371","__typename":"TagType"},{"name":"ethernetcover","id":"88118","__typename":"TagType"},{"name":"ethernetport","id":"122625","__typename":"TagType"}],"thingiverseLink":null,"filesType":null,"previewFile":{"id":"1647717","filePreviewPath":"media/prints/351646/stls/3158670_06ea144b-86fb-44d3-a928-cdc84702b2bc/ethernet_cover_v2_default_preview.png","__typename":"STLType"},"license":{"id":"1","disallowRemixing":false,"__typename":"LicenseType"},"remixParents":[{"id":"189817","modelId":null,"modelName":null,"modelAuthor":null,"model":null,"url":"https://www.thingiverse.com/thing:4736807","urlAuthor":"Critterninja","urlImage":"https://cdn.thingiverse.com/assets/5f/b4/1c/86/b9/featured_preview_ETH_Plug_NoSupport.png","urlTitle":"Antidust Ethernet plug - No Supports","urlLicense":null,"urlLicenseText":null,"__typename":"PrintRemixType"}],"remixDescription":null,"__typename":"PrintType","user":{"id":"195541","handle":"kerngebiet","verified":false,"dateVerified":null,"publicUsername":"kerngebiet","avatarFilePath":"media/auth/avatars/80/808d404d-960c-4272-8be6-61d6c9eb731a.png","badgesProfileLevel":{"profileLevel":20,"__typename":"BadgesProfileLevelType"},"__typename":"UserType","isFollowedByMe":false,"canBeFollowed":true,"designer":false}},"unavailableModel":null,"replies":[]}}}

Ethernet Port Dust Cap/Cover - No Supports

Ethernet Port Dust Cap/Cover - No Supports
