Just a nice ratchet for holding your misc. cables together.

This is my second ratchet design iteration. The previous ones required some assembly and M3 nut & bolt but in this one the single STL file contains both parts preassembled so you don't need to join them after the print.
I left 0.3 mm gaps between the parts and printed from PLA with 0.2 mm layer height, without any support. The result is so fantastic I'll continue use this pre-assembled methodology in my future designs!
I printed it on my Prusa i3 MK2 which did not get the multi-extruder upgrade yet but to bow before the father of my wonderful printer I rendered an image where the lock mechanism is Prusa-orange :)

Link to the Fusion 360 design in case you want to tweak on it: http://a360.co/2sGiw2C

Update #20200524: I have uploaded a 25 and a 40 mm version with dull teeth.

Update #20210117: base on user request I have uploaded a 32 mm dull teeth version.

Update #20220926: don't forget to check out the spring loaded DIN rail mount version: https://www.printables.com/model/283611-spring-loaded-din-rail-ratchet-fat-chicken-edition

Update #20230202: I have uploaded 20-25-30-40 mm dull teeth versions with 0.4 mm layer gaps in the hinge.
