Really nice work!
Hall aus Bayer, vielen Dank für die Druckdateien. Ich habe aber ein Problem mit dem umschreiben der bin Datei. Wäre es möglich mir die geänderte BIN mit der richtigen Servorichtung zu schicken. Danke und Grüße Alex
Hello and thank you for the 3d files. Great work, excellent. I have printed the case but it appears that the Heltec module dimensions have changed a little. I have v3.1 of the Heltec module and the case supports no longer align correctly with the opening for the screen, they are out by about 2mm in both the X and Y direction. Will you be updating the design please?
View 2 more comments
@SalMancina_2880360
Hello back!
Firstly, thank you for your detailed answer. Perhaps it would be a simple solution if I simply make the two small support brackets flat (remove the small bevelled edge on both small supports).
In my first version, I simply screwed a small screw into one of the small supports (see last photo). In the current version, I simply used superglue. This works well and as the USB port of the controller is quite exposed, you can also download software updates on it later, even if the controller is firmly glued. Hot glue will certainly work too.
Best regards!
Ralf
@rallef80_657331
Hi, perhaps the supports could be made into 3 separate items that can be printed on their own. It would then be easy to superglue them into the correct position to suit the Heltec board variants as their design changes.
Regards, Sal
